Technical Specification

Power supply

120Volt/60Hz

capacity

4.2 Cu.Ft. /118 Liters

Cooktop Specifications

Cooking Surface

Venturi / Open Burners

Grate Color

Black Gloss

Grate Material

Steel

Grates

Square

Knob Type

Plastic CC

Left Front

9000 BTU

Left Rear

9000 BTU

Right Front

9000 BTU

Right Rear

9000 BTU

Electrical Specifications

Power Supply Connection Location

Rear Centerline Lower

Cooking Controls

Bake

Yes

Broil

Broil Variable (400 - 500°F)

Clear Button

Yes

Timer

Yes

Drawer

Drawer Functionality

Broil & Serve

Handle

Short Handle

Oven Specifications

Bake

18000 BTU

Baking System

Even Baking Technology

Broil

16000 BTU

Broiling System

Vari-Broil High/Low

Cleaning System

Manual Clean

Interior Color

Slate Blue

Interior Lighting

1 Incandescent

Rack Configuration

2 Standard

Rack Positions

5 positions

Oven Window

Standard Visualite

Exterior Specifications

Control Panel Finish

Metal

Cooktop Finish

Porcelain

Door Finish

Metal

Drawer Finish

Metal

Exterior Finish

Painted

Weight and Dimension

Unit Weight

135 Lbs.

Unit Dimension

45.75"H x 29.62"W x 25.75"D
