Technical Specifications

Voltage

120Volt/60Hz

Capacity

4.2 CU.FT.

Leveling Legs

4 Adjustable

Power Type

Gas

Installation Type

Free-Standing

Certifications & Approvals

Agency Approval

CSA

Cooktop Specifications

Cooking Surface

Upswept / Sealed Burners

Grate Color

Black Matte

Grate Material

Cast Iron

Grates

Individual

Knob Color

Black

Knob Type

Plastic Black

Left Front

9500 BTU

Left Rear

9500 BTU

Right Front

12000 BTU

Right Rear

5000 BTU

Exterior Specifications

Cooktop Finish

Black Porcelain

Drawer Finish

Black Metal with Stainless Steel Overlay

Exterior Finish

Painted

Manifold Panel

Black

Door Finish

Exterior Specifications

Glass with Stainless Steel overlay

Cooking Controls

Bake

Yes

Broil

Broil Variable (400 - 500°F)

Clear Button

Yes

Timed Cook Option

Yes

Timed Shut-off

12 hours

Timer

Yes

Drawer

Drawer Functionality

Broil & Serve™

Handle

Stainless Steel

Handle Color

Exterior Specifications

Stainless Steel

Oven Specifications

Oven 1 Bake

18000 BTU

Oven 1 Baking System

Even Baking Technology

Oven 1 Broil

16000 BTU

Oven 1 Broiling System

Vari-Broil™ High/Low

Oven 1 Cleaning System

Manual Clean

Oven 1 Interior Color

Slate Blue

Oven 1 Interior Lighting

1 Incandescent

Oven 1 Rack Configuration

2 Standard

Oven 1 Rack Positions

5 positions

Oven 1 Type

Main

Oven Window

Extra-Large Visualite®

Control Panel Finish

Exterior Specifications

 Black Metal with Stainless Steel Overlay

Electrical Specifications

Power Supply Connection Location

Rear Centerline Lower

Weight And Dimensions

Unit Weight

135 lbs.

Unit Dimensions

47.75"H X 29.88"W X 28.41"D
