Technical Specification

Power Supply

208Volt/ 240 Volt-60Hz

Capacity

4.6 Cu.ft.

General Specifications

Power Type

Electric

Size

30''

Installation Type

Slide-In

Oven Specifications

Oven 1 Cleaning System

Self-Clean w/Steam Clean Option

Oven 1 Convection

2500 Watts

Oven 1 Interior Lighting

2 Halogen

Drawer

Drawer Functionality

Storage

Certifications & Approvals

ADA Compliant

Yes

UL Agency Approval

Yes

Sabbath Mode

Yes

Cooktop

Center

100 Watts (Keep Warm)

Hot-Surface Indicator Light

4 (integrated in display)

Left Front

6/9" - 1400/3000 Watts

Left Rear

6" - 1200 Watts

Right Front

9/12" - 2000/3200 Watts

Right Rear

6" - 1200 Watts

Cooking Controls

Bake

Yes

Cook Duration

Yes

Broil

Variable

Cancel

Yes

Set Clock

Yes

Convection Conversion

Yes

Automatic Oven (Delay Cook & Off)

Multiple Functions

Keep Warm

Yes

Lockout

Yes

Numerical Keypad

Yes

Quick Preheat

Yes

Self-Clean

2 3 4 Hours

Start Button

Yes

Probe

Yes

Timer

Yes

Cooktop Specifications

Knob Color

White

Exterior Specifications

Control Panel Finish

Plastic

Door Finish

Glass

Drawer Finish

Metal

Handle Color

Metal

Oven

Bake

2500 Watts

Baking System

True Hidden Bake

Broil

6 pass 3400 Watts

Broil System

Variable (400°F to 550°F)

Convection System

2500 Watt Single Fan Convection

Interior Color

Midnight Black

Rack Positions

5 positions

Window

XL Window

Electrical Specifications

Amps @ 240 Volts

52.5 / 45.7

Connected Load (kW Rating) @ 240V

12.6 / 9.5

Minimum Circuit Required (Amps)

40A

Power Supply Connection Location

Left Rear Bottom

Weight And Dimensions

Unit Weight

180 Lbs.

Shipping Weight

205 Lbs.

Unit Dimensions

35.75/36.62”H X 30”W X 28.31”D
