General Specifications

Voltage

120Volt/60Hz

Capacity

5 Cu. Ft.

Leveling Legs

4 Adjustable

Power Type

Gas

Installation Type

Free-Standing

Cooktop

Cooking Surface

Porcelain

Center

9500 BTU (Round)

Left Rear

14000 BTU

Right Rear

5000 BTU

Left Front

9500 BTU

Right Front

17000 BTU

 Electronic Ignition

Yes

Grate Color

Black Matte

Grate Material

Cast Iron

Grates

3 Continuous Grates

Knob Color

Stainless Steel Appearance

Knob Type

Plastic CC

Certifications & Approvals

Agency Approval

CSA Blue Star / CSA Blue Flame

Drawer

Drawer Functionality

Storage

Drawer Handle

Integrated

Cooking Controls

Bake

Yes

Broil

Yes

Cancel Button

Yes

Door Lock

Yes

Quick Bake Convection

Yes

Set Clock

Yes

Lockout

Yes

Self-Clean

2 3 Hours

Start Button

Yes

Timer Function

Yes

Control Panel Finish

Exterior Specifications

Aluminum Panel

Oven

Bake

18000 BTU

Broil

13500 BTU

Baking System

Even Baking Technology

Broiling System

Vari-Broil™ High/Low

Cleaning System

Self-Clean

Convection System

Quick Bake

Hidden Bake Element

Yes

Oven 1 Interior Color

Slate Blue

Interior Lighting

1 Incandescent

Rack Positions

6 positions

Rack Configuration

2 Standard

Type

Main

Window

Extra-Large Visualite®

Exterior

Cooktop Finish

Porcelain

Drawer Finish

Stainless Steel Smudge-Proof

Exterior Finish

Painted

Weight And Dimension

Unit Weight

205 Lbs.

Unit Dimension

48.50"H x 29.87W x 29.25"D
