Technical Specifications

Power Supply

120Volt/60 Hz

Capacity

5 Cu.Ft.

Size

30''

Power Type

Gas

Leveling Legs

4 Adjustable

Made In USA

Yes

Installation Type

Free-Standing

Cooktop

Center

Oval 10000 BTU

Cooking Surface

Porcelain

Electronic Ignition

Yes

Grate Color

Black Matte

Grate Material

Cast Iron

Grates

3 Continuous Grates

Left Front

9500 BTU

Left Rear

12000 BTU

Right Front

18000 BTU

Right Rear

5000 BTU

Electrical Specifications

Min Circuit Required

15A

Certifications & Approvals

Sabbath Mode

Yes

Exterior Specifications

Knob Color

Black

Cooking Controls

Bake:

Yes

Broil:

Yes

Cancel Button

Yes

Set Clock

Yes

Convection Bake

Yes

Convection Conversion

Yes

Convection Roast

Yes

Door Lock

Yes

Keep Warm

Yes

Lockout

Yes

Keypad Entry Time & Temp

Yes

Self-Clean

2 3 4 Hours

Start Button

Yes

Temperature Probe

Effortless Probe

Timer Function

Yes

Drawer

Drawer Functionality

Storage

Drawer Handle

Integrated

Oven

Bake

18000 BTU

Baking System

Even Baking Technology

Broil

13500 BTU

Broiling System

Variable (400°F to 550°F)

Cleaning System

Self-Clean

Convection

350 Watts

Convection System

350 Watt True Convection

Hidden Bake Element

Yes

Interior Color

Slate Blue

Interior Lighting

1 Incandescent

Rack Configuration

3 Heavy Duty Racks

Rack Positions

6 positions

Window

Extra-Large Visualite

Exterior

Cooktop Finish

Porcelain

Drawer Finish

Metal

Exterior Finish

Painted

Weight and Dimension

Unit Weight

200 Lbs.

Unit Dimension

46.62”H x 29.87”W x 29.25”D
