Technical Specifications Power Supply 120Volt/60Hz Capacity 14 Place setting Sound Package UltraQuiet IV Leveling Legs 4 Sound Level 54.0 dBA Energy Efficiency Tier Tier I Power Type Electric Size 24'' Installation Type Built-In Upper Rack Cup Shelf 2 Rack Handles Yes Stemware / Champagne Glass Holders Yes Plate - Height Clearance 8" Certifications & Approvals NSF® Certified Yes CSA Listed Yes UL Listed 1-UL Listed ENERGY STAR® Certified Yes CEE Tier 1 Meets ASSE 1006 Requirements Yes Exterior Specifications Exterior Finish White Door Latch Pull Latch Door Type Stay-Put Controls Controls Super Slimline Control Lock Yes Delay Start (hours) 2 - 4 - 6 Hours Lower Rack Height Clearance 11" - 13" Silverware Basket Ultra I Rack System Rack Coating Nylon TufRacks Cycles Number of Cycles 5 Quick Yes Upper Rack Only Yes Normal Yes Rinse Only Yes Heavy Yes Dishwasher Specifications Satellite Spray Arm BladeSpray Tub Design Tall-Tub Design Filtered Water 100% Drying System Static Vent Integral Air Gap on Supply Yes Smart Soil Sensor Yes Water Pressure 20 – 120 PSI Filter Stainless Steel Food Disposer Yes Filter Trap Removable Hard Food Disposer Hard Food Disposer & Filtration Wash Levels 5 Rinse Aid Dispenser Adjustable with Indicator Interior Greystone Water Usage 4.9 - 8.5 Gallons Wash System Direct Feed Options NSF® Certified Yes Hi-Temp Wash Yes Heat/No Heat Dry Yes Electrical Specifications Amps @ 120 Volts 10.0 Power Supply Connection Location Front Right Bottom Weight and Dimension Unit Weight 78 lbs. Shipping Weight 83 lbs. Unit Dimension 33.50"–35"H x 24"W x 25”D
Technical Specifications
Power Supply
120Volt/60Hz
Capacity
14 Place setting
Sound Package
UltraQuiet IV
Leveling Legs
4
Sound Level
54.0 dBA
Energy Efficiency Tier
Tier I
Power Type
Electric
Size
24''
Installation Type
Built-In
Upper Rack
Cup Shelf
2
Rack Handles
Yes
Stemware / Champagne Glass Holders
Plate - Height Clearance
8"
Certifications & Approvals
NSF® Certified
CSA Listed
UL Listed
1-UL Listed
ENERGY STAR® Certified
CEE Tier
1
Meets ASSE 1006 Requirements
Exterior Specifications
Exterior Finish
White
Door Latch
Pull Latch
Door Type
Stay-Put
Controls
Super Slimline
Control Lock
Delay Start (hours)
2 - 4 - 6 Hours
Lower Rack
Height Clearance
11" - 13"
Silverware Basket
Ultra I
Rack System
Rack Coating
Nylon TufRacks
Cycles
Number of Cycles
5
Quick
Upper Rack Only
Normal
Rinse Only
Heavy
Dishwasher Specifications
Satellite Spray Arm
BladeSpray
Tub Design
Tall-Tub Design
Filtered Water
100%
Drying System
Static Vent
Integral Air Gap on Supply
Smart Soil Sensor
Water Pressure
20 – 120 PSI
Filter
Stainless Steel
Food Disposer
Filter Trap
Removable
Hard Food Disposer
Hard Food Disposer & Filtration
Wash Levels
Rinse Aid Dispenser
Adjustable with Indicator
Interior
Greystone
Water Usage
4.9 - 8.5 Gallons
Wash System
Direct Feed
Options
Hi-Temp Wash
Heat/No Heat Dry
Electrical Specifications
Amps @ 120 Volts
10.0
Power Supply Connection Location
Front Right Bottom
Weight and Dimension
Unit Weight
78 lbs.
Shipping Weight
83 lbs.
Unit Dimension
33.50"–35"H x 24"W x 25”D
Orbit Clean Spray ArmDish Sense Technology Stemware Holders & 2 Cup shelves54 DBAs. Stay-Put DoorStainless Steel FiltrationGreystone, Polymer TubMultiple-Cycle Options2 - 6 Hour Delay StartNSF® CertifiedENERGY STAR® Certified Built with American PrideColor White
