Technical Specifications

Power Supply

120Volt/60Hz

Capacity

14 Place setting

Sound Package

UltraQuiet IV

Leveling Legs

4

Sound Level

54.0 dBA

Energy Efficiency Tier

Tier I

Power Type

Electric

Size

24''

Installation Type

Built-In

Upper Rack

Cup Shelf

2

Rack Handles

Yes

Stemware / Champagne Glass Holders

Yes

Plate - Height Clearance

8"

Certifications & Approvals

NSF® Certified

Yes

CSA Listed

Yes

UL Listed

1-UL Listed

ENERGY STAR® Certified

Yes

CEE Tier

1

Meets ASSE 1006 Requirements

Yes

Exterior Specifications

Exterior Finish

White

Door Latch

Pull Latch

Door Type

Stay-Put

Controls

Controls

Super Slimline

Control Lock

Yes

Delay Start (hours)

2 - 4 - 6 Hours

Lower Rack

Height Clearance

11" - 13"

Silverware Basket

Ultra I

Rack System

Rack Coating

Nylon TufRacks

Cycles

Number of Cycles

5

Quick

Yes

Upper Rack Only

Yes

Normal

Yes

Rinse Only

Yes

Heavy

Yes

Dishwasher Specifications

Satellite Spray Arm

BladeSpray

Tub Design

Tall-Tub Design

Filtered Water

100%

Drying System

Static Vent

Integral Air Gap on Supply

Yes

Smart Soil Sensor

Yes

Water Pressure

20 – 120 PSI

Filter

Stainless Steel

Food Disposer

Yes

Filter Trap

Removable

Hard Food Disposer

Hard Food Disposer & Filtration

Wash Levels

5

Rinse Aid Dispenser

Adjustable with Indicator

Interior

Greystone

Water Usage

4.9 - 8.5 Gallons

Wash System

Direct Feed

Options

NSF® Certified

Yes

Hi-Temp Wash

Yes

Heat/No Heat Dry

Yes

Electrical Specifications

Amps @ 120 Volts

10.0

Power Supply Connection Location

Front Right Bottom

Weight and Dimension

Unit Weight

78 lbs.

Shipping Weight

83 lbs.

Unit Dimension

33.50"–35"H x 24"W x 25”D
